Bore and Dowel

CNC (Computer Numeric Control) drill and dowel inserting machines for fully automatic bore, glue and dowel insertion. Use the Index CNC to provide automated precision control of your production process. The Index series of drill, glue and dowel machining centers provides a compact frame with speed, accuracy, flexibility and quality.

bore & dowel

Standard Features

Standard Features

Horizontal drilling for dowels, pilot holes.

Optional Features

  • HSK 63-F quick-change panel groove spindle
  • Additional horizontal spindles (pilot drilling for confirmat screw)
  • Vertical overhead boring spindle
  • Longer table lengths
  • CNC control of additional axis
  • Additional work zones
  • Additional work zones dedicated for rail end work (for doweling face frames)
  • Bar-code reader
  • Parametric programming (standard or built to customer specifications)
  • Louver grooving
  • Dado routing
  • “Modeez Clip” routing

Bore and Dowel

Models

Models



The H49 is a horizontal point-to-point bore and dowel insertion machining center.

It is designed to CNC position the spindle, bore a hole, then CNC position the inserter, inject glue or water (for pre-glued dowels), and fire the dowel into the hole.

A part is placed into the work zone referencing the back and side fences. The green palm button is pressed and the clamps secure the part into place. The machining is now ready to begin in the work zone. There are 2 zones standard in the base model H-49 allowing for pendulum processing. While the one part is being machined, the other zone can be loaded and queued for machining.
